4 Ply


4 PLY airbags are designed for Truck, Intermodal, Railroad and Sea Containers

4 PLY Kraft paper dunnage air bags have an outstanding load stabilizing capacity, withstanding tons of pressure and resistance to load shifting. The bags are constructed of multiple layers of high strength extensible Kraft paper and inner liner is constructed of coextruded polyethylene film for added protection against loss of air pressure.

  • Re-usable
  • Re-cyclable
  • Moisture resistant
  • Easy to inflate and deflate
  • Working pressure (Max.) = 4,35 PSI / 0.30 Bar
  • PP Equivalent: Level 2 Airbags

Truck and container applicable, AAR Truck and container applicable, AAR Railroad applicable Ship applicable

Size (cm) Quantity per Pallet FRONT Weight of Pallet (kg) FRONT Pallet Size
60x60 400   100x120x115
60x90 400   100x120x115
60x120 350   100x120x115
60x150 300   100x120x115
60x180 300   100x120x115
60x210 275   100x120x115
60x240 275   100x120x115
90x90 300   100x120x115
90x120 300   100x120x115
90x150 275   100x120x115
90x180 250   100x120x115
90x210 200   100x120x115
90x240 200   100x120x115
120x120 275   100x120x115
120x150 225   100x120x115
120x180 175   100x120x115
120x210 150   100x120x115
120x240 150   100x120x115
